Carli Suspension

2017-2024 FORD F250/F350 SUPER DUTY COMMUTER 2.0 4.5"/5.5" Lift Carli LIFT KIT

$2,885.00 USD
$2,885.00 USD
Sale Sold out
Shipping calculated at checkout.
Year

Diesel trucks ONLY.

4.5" Lift for 2017, 2018, 2019 F250/F350

5.5" Lift for 2020, 2021, 2022, 2023, 2024 F250/F350

3.5" for Tremors

Want to customize your kit with more add-ons? After you add this kit to your cart, check out the link below. Leaf spring and sway bar options are required for this kit

https://square1offroad.com/search?q=f250+carli&options%5Bprefix%5D=last

Carli's Suspension's 2017-22 Ford Super Duty Commuter 2.0 system is designed for people seeking the best ride on road an in light off road situations.�

The 2020+ Ford F250/350 Platform is the same as the 17-19 but they lowered the front 1" and the rear 1"-1.5" depending on the cab configuration and 250/350 designation. For this reason, the only change to the suspension systems will be the stated lift height. The 4.5" Lift Systems from the previous generation, 2017-19, are now 5.5" for the 2020.


The truck will sit 4.5�/5.5" higher in the front and have more wheel travel thanks to the taller, Progressive Rate Coil Springs. Radius Arm Drop Brackets reset the pivot point and keep the travel linear for the best ride while the Sway Bar Link & Drop Brackets Kit resets the sway bar engagement point. The End Link Kit is listed as an �option�, but it�s necessary to run. Bump Stop Drops protect the shocks from over-compressing, the Adjustable Track Bar centers the front axle and Stainless Brake Lines firm up braking and ensure there is enough line for the newfound travel. To round off the front end, Carli includes Caster Shims to help achieve proper caster. While other "lifts" may cheap out on all these parts, Carli includes everything you need for the best ride and geometry possible.�

The Commuter is the beginning of Carli's no-compromise, custom tuned suspensions. The 4.5� lift variation was tuned with the Progressive Add-a-Pack atop the Carli Fabricated 2� Block. The Add-a-Pack installs in place of the lower, factory overload spring to increase small bump sensitivity while maintaining payload and towing spec.�The custom tuning in the rear Carli SPEC 2.0� shock is optimized to control the combination of our Progressive Add-a-Pack combined with the factory main pack, so we don't advise using the full leaf pack with this system.



COMPONENTS

-CS-FMRC-05�Carli 4.5" Progressive Coil Springs
-CS-FATB-17�Carli 2017+ Ford Super Duty Adjustable Track Bar
-CS-FC20SPKG-45-05�Carli Commuter 4.5" Shock Package
-CS-FORDBBL-4.5-17�Carli 2017+ Ford Stainless Brake Lines
-CS-FRAD-17�Carli 2017+ Ford Super Duty Radius Arm Drop Brackets
-CS-FBDF-4.5-17�Carli 2017+ Ford 4.5" Front Bump Stop Drops
-CS-FCASTERSHIM-4.5�Carli Ford Super Duty Caster Correction Shims

OPTIONAL

-Carli 2017+ Ford Super Duty Adjustable Track Bar
-Carli Ford Super Duty Fabricated Radius Arms
-Carli 2017+ Front Sway Bar Drop Brackets

�

CUSTOM TUNED // Unlike your average lift, Carli Suspension uses only custom tuned shocks. Each shock package goes through months of testing, development, tuning, and valving. It's one of the only leveling kits at this price that comes with custom tuned shocks, and the difference in ride is impressive.

�

LEAF PACK OPTIONS // Balancing ride and capability, the add a pack retains factory payload but improves small bump compliance by increasing the leaf count and reducing leaf thickness in half the pack. With the full leaf pack, a 15% payload reduction gets the best possible ride quality from the rear of the truck. Small chatter or large hit, this leaf pack will swallow it whole.

�

SWAY BAR UPGRADE // Eliminates the harshness caused by the stiff factory sway bar, letting your suspension do its job and move independently. This is one of the single biggest improvements you can make to your truck�s ride. To keep the factory ride, select the end link option.

�

RADIUS ARMS // Hand fabricated and welded in California with the highest quality joints for improved flex, these arms are a high strength control arm replacement. These arms feature a fabricated notch making it possible to clear 37�s on a wider range of wheels.
