Diode Dynamics Elite LED Fog Lights 2021-2023 Ford F150
PREORDER - April 2023 ship date
- Two (2) Ford F-150 Elite Series Fog Lamps
- Two (2) Plug-and-Play Harnesses
- Two (2) Molex Sealing Plugs
- One (1) Adjuster Tool
- Installation Guide
- Triple LED projectors for maximum output and intensity
- Selectable-color Blade DRL
- Modern welcome sequence
- Integrated sequential amber turn signal
- Optional show mode (requires Elite Max headlamp)
- Engineered and Assembled in USA - 8 Year Warranty
Introducing Elite Series LED Fog Lights for the 2021+ Ford F-150 from Diode Dynamics! These foglamps were designed for maximum performance, and they are 100% engineered and assembled in the USA. With the latest technology and features, they redefine what’s possible for aftermarket foglamps!
With OEM-grade quality, these Elite Series Fog Lights will add a switchback sequential turn signal, welcome sequence, a brighter DRL bar with selectable color, and optional show mode and off-road lighting. Plus, you’ll get unmatched performance and output, backed by an 8-year warranty.
Maximum Light Output. First and foremost, the Elite Series LED Fog Lights provide full LED illumination with three modern, rectangular LED projectors. This unit provides higher intensity than both factory options, shining with a wide beam of light to provide excellent foreground coverage. This supplemental light is a great help in inclement weather, such as fog or snow, or any time you need to add extra light to the front or sides of the vehicle.
White or Yellow. The Elite Series Fog Lights for the 2021+ F-150 are available in a cool white or selective yellow output color.
The white is a 6000K color temperature, which is a true cool white output. This will perfectly match other LEDs on your vehicle, such as DRLs or running lights.
The selective yellow option is 3000K in color temperature, which is great for high contrast in inclement weather, or in providing a distinctive look on the road. The yellow lamp consists of a yellow multi-die LED emitter paired with a yellow-tinted lens, to provide unmatched output and optical efficiency, even with the intense yellow output.
Welcome Sequence. When you’re ready to hit the road, your Elite Series Fog Lights will show off their capabilities with a gradual illumination of the LEDs. This provides an unmistakable indicator of the modern technology packed inside. If you have our Elite Series Headlights for the 2021+ F-150 installed as well, they will both illuminate in a coordinated sequence, thanks to the included communication wire. Note that the startup sequence is programmable, and can be easily disabled if desired.
Selectable DRL - On the Fly. These fog lamps feature a selectable DRL, to customize the style of your truck. They are built with solid blade-style optics for a truly premium look. You can choose between a crisp white and amber color. The best part? You don’t even have to pop the hood. Our patent-pending technology allows you to program your foglamps from inside the vehicle, using existing controls. No extra switches, wires, or controllers required!
Switchback Sequential Turn Signal. The Elite Series Fog Lights will flash in a sequential amber pattern that sweeps from inside to out any time the turn signal is activated. When you’re done making your turn, they’ll switch back to the white parking light, or your selected DRL color.
Show Mode and Off-Road Capability (optional). As if the other features weren’t enough, the Elite Series Fog Lights can be installed in conjunction with Elite Series Headlights, to unlock a show mode and off-road lighting features. When Off-Road mode is activated on the headlights, your fog lights will do their part by lighting up on full blast too. And whether you’re parked at a meet or just want to be seen, you can activate the show mode on your headlights, and the fogs will follow suit. Choose between four functions: Gradual, White Strobe, Amber Strobe, or Amber/White Strobe. Please note that Elite Max headlights are required to use these extra features.
Plug-and-Play Installation. These foglamps were designed to be a direct replacement for both halogen and LED-equipped F-150s, in all trim levels. Simply remove your factory foglamp assembly and ours will bolt right in its place. A plug-and-play wire harness is included to hook them up to your factory connector, and a single wire connector is included if you’d like to add the turn signal function. With built-in adjusters, the lamps can be aimed using the provided adjustment tool.
Assembled with Quality - in the USA. Elite Series Fog Lamps are assembled in the USA using OEM-grade materials, including a precision aluminum casting, UV-coated outer lens, copper-core circuit board, custom-designed optics, and multi-die automotive emitters. After being assembled by Diode Dynamics in St. Louis, Missouri, they are robotically sealed with urethane epoxy for long-lasting protection against moisture, and packaged in form-fit foam for safe transportation. No expense has been spared, from materials to assembly, right here in America.
Proven Reliability - Backed for 8 Years. Like our popular Stage Series lineup, Elite LED foglamps have been extensively tested for long-term operation from -40 to 185 degrees F, along with vibration, moisture intrusion, and corrosion testing. All of these tests are completed to SAE standards, just like the factory components on your vehicle. With integrated moisture-proof vents, the lamps can “breathe” with changes in temperature, maintaining a strong seal over time. And with built-in circuit protection for voltage spikes and reverse polarity, these lights will keep working for years. They are backed by an industry-leading 8-year limited warranty.
Experience. After over a decade in business, Diode Dynamics is one of the most trusted names in automotive LED lighting. We directly assemble and engineer our own products in the United States, allowing for higher quality and performance, with the newest and brightest LED technology. No matter what you're driving, we pride ourselves in offering only the best possible LED solutions. Please contact us if you'd like to discuss your lighting project!
